        Learn more by watching our HAGER NT102C | 2 Amp Single Pole 10kA Circuit Breaker | C Curve video.

        Description

        HAGER NT102C | 2 Amp Single Pole 10kA Circuit Breaker | C Curve

        The Hager NT102C is a C Curve three pole circuit breaker which protects and control circuits against overloads and short-circuits. The NT102C circuit breaker is rated at 10kA and is suitable for commercial and Industrial applications.

        Features:

        • 2 Amp
        • 1 Pole
        • 10kA
        • Curve C
        • Rated short circuit breaking capacity 10 kA
        • Frequency: 50/60 Hz
        • Rated insulation voltage: 500 V
        • Operating temperature: -25 to 60 °C
        • Electric endurance in number of cycles: 4000
        • Number of mechanical operations: 20000
        • Top and bottom screw terminals connection capacity with massive conductor: 1/35 mm²
        • Top and bottom screw terminals connection capacity with flexible cable: 1/25 mm²
        • Tightening torque: 2,8Nm
        • Height of installed product: 83 mm
        • Width of installed product: 17.5 mm
        • Depth of installed product: 70 mm

        (NT102C)

        Warranty

        Warranty starts from Invoice Date

        Domestic Use: 2 Year
        Commercial Use: 2 Year
        Warranty Method: Return to Sparky Direct

        Specifications

        These specifications and characteristics outline physical, mechanical, electrical details.

        Brand Hager Electrical
        SKU NT102C
        Barcode # 3250614806926
        Shipping Weight 0.0287kg
        Shipping Width 0.080m
        Shipping Height 0.035m
        Shipping Length 0.070m
        Shipping Cubic 0.000196000m3
        TYPE VALUE
        Type Circuit Protection
        Brand Hager Electrical
        Rated Current (A) 2
        Height (mm) 83
        Width (mm) 17.5
        Depth (mm) 70
        Standards AS/NZS 60898-1
        Mounting Din Rail
        Voltage (V) 240V
        Number of Poles 1
        IP Rating IP20 ( IP40 Enclosed )
        Breaking Capacity 10kA
        Curve C
