Learn more by watching our Mitsubishi Electric Air Conditioner Split System 7.8kW Cooling - 9.0kW Heating | MSZ-AP80VGD video.
The Mitsubishi Electric MSZ-AP80VGD Split System Air Conditioner offers powerful climate control with 7.8kW cooling and 9.0kW heating capacities, ensuring year-round comfort for homeowners. This advanced unit features a "Quiet Mode" setting that operates as low as 30dB, perfect for bedrooms and quiet spaces. The dual barrier coating minimizes dust and greasy dirt buildup, keeping the air conditioner cleaner and requiring less maintenance.
Night mode reduces the brightness of the operation indicator light, disables beep noises, and limits the noise level of the outdoor unit, making it ideal for restful sleep. Using R32 refrigerant, this system is more energy-efficient and environmentally friendly compared to R410A. Optional Wi-Fi control allows you to manage the air conditioner remotely from your smartphone or tablet. The system also includes a weekly timer, vertical and horizontal vanes for optimal airflow, and a full inverter for enhanced performance. The optional Plasma Quad Connect air purifying filter significantly improves indoor air quality by inhibiting pollutants such as viruses, bacteria, and allergens. Additional features include a blue fin condenser and i-save mode for enhanced durability and energy efficiency.
AC box sizing:
Q: Is this air conditioner quiet enough for bedrooms?
A: Yes, the unit features a "Quiet Mode" setting that operates as low as 30dB in heating mode, making it ideal for bedrooms and other quiet environments.
Q: What type of refrigerant does this air conditioner use?
A: It uses R32 refrigerant, which is more energy-efficient and has a lower environmental impact compared to R410A.
Q: Does the air conditioner have any special coatings?
A: Yes, the dual barrier coating reduces dust and greasy dirt accumulation, while the blue fin condenser has an anti-corrosion treatment.
Q: Is there an option for air purification?
A: Yes, the optional Plasma Quad Connect air purifying filter can improve indoor air quality by inhibiting pollutants like viruses, bacteria, allergens, and dust.
Q: How does the i-save mode work?
A: The i-save mode allows you to recall a preset temperature setting at the press of a button, ensuring efficient and comfortable operation.
Q: What additional features does this air conditioner offer?
A: Other features include night mode, weekly timer, vertical and horizontal vanes, full inverter technology, and long airflow for even air distribution.
(MSZ-AP80VGD)
Warranty starts from Invoice Date
5 Year Manufactures Warranty
Specification | Details |
---|---|
Indoor Unit | MSZ-AP80VG(D) |
Outdoor Unit | MUZ-AP80VG(D)2 |
Refrigerant | R32 |
Cooling Capacity [Rated] | 7.8kW |
ZERL Star Rating (Cooling) | Hot: 3.5, Average: 3.0, Cold: 3.5 |
Sound Pressure Level (Cooling) | In [Quiet-Lo-Mid-Hi-SHi] dB(A) - 30-37-41-45-53 OUT (PWL) dB(A) - 56 (69) |
Heating Capacity [Rated] | 9.0kW |
ZERL Star Rating (Heating) | Hot: 3.0, Average: 2.5, Cold: 2.0 |
Sound Pressure Level (Heating) | In [Quiet-Lo-Mid-Hi-SHi] dB(A) - 30-37-41-45-53 OUT (PWL) dB(A) - 56 (69) |
Indoor Unit Dimensions [H×W×D] | 325×1100×257 |
Indoor Unit Weight | 17kg |
Outdoor Unit Dimensions [H×W×D] | 880×840×330 |
Outdoor Unit Weight | 55kg |
System model name | MSZAP80VG2KIT |
System model name (DRED Capable) | MSZAP80VGD2KIT |
These specifications and characteristics outline physical, mechanical, electrical details.
Brand | Mitsubishi Electric Air Conditioners |
SKU | MSZ-AP80VGD |
Shipping Weight | 72.0000kg |
Shipping Width | 1.940m |
Shipping Height | 1.350m |
Shipping Length | 0.587m |
Shipping Cubic | 1.537353000m3 |
TYPE | VALUE |
---|---|
Brand | Mitsubishi Electric |
Range | MSZ-AP Series |
Energy Star Rating - Heating | 2.5 Stars |
Energy Star Rating - Cooling | 2 Stars |
Nominal Cooling (kW) | 7.8 |
Nominal Heating (kW) | 9.0 |
Cooling Running Current (A) | 10.8 |
Heating Running Current (A) | 11.3 |
Indoor Dimensions (H x W x D ) mm | 325 x 1100 x 257 |
Outdoor Dimensions (H x W x D ) mm | 880 x 840 x 330 |
Pipe Size (Gas) OD mm (inch) | 12.7 (1/2) |
Pipe Size (Liquid) OD mm (inch) | 6.35 (1/4) |
Refrigerant | R32 |
Breaker Size (A) | 20 |
