The NLS 30838 16A RCBO Single Pole provides reliable circuit protection with a 6KA short circuit capacity and A-Type tripping for sensitive applications. Designed for single-phase systems, it ensures efficient fault detection, including residual and overload currents.
Pre-wired tails simplify the installation process, saving time and effort. Its compact form factor is ideal for modern electrical distribution boards, making it a practical choice for safety compliance.
Q: What type of applications is this RCBO suitable for?
A: It is suitable for residential and light commercial electrical installations.
Q: Does this RCBO support dual-function protection?
A: Yes, it protects against both residual currents and overloads.
Q: Are the pre-wired tails a standard feature?
A: Yes, the pre-wired tails come standard to ensure easy and quick installation.
(30838)
Warranty starts from Invoice Date
Domestic Use: 2 Year
Commercial Use: 2 Year
Warranty Method: Return to Sparky Direct
These specifications and characteristics outline physical, mechanical, electrical details.
| Brand | NATIONAL LIGHT SOURCES |
| SKU | 30838 |
| Shipping Weight | 0.1640kg |
| Shipping Width | 0.076m |
| Shipping Height | 0.030m |
| Shipping Length | 0.107m |
| Shipping Cubic | 0.000243960m3 |
| TYPE | VALUE |
|---|---|
| Type | Circuit Protection |
| Brand | National Light Sources |
| Rated Current (A) | 16 |
| Height (mm) | 92 |
| Width (mm) | 18 |
| Depth (mm) | 77 |
| Standards | AS/NZ 61009-1 |
| Mounting | Din Rail |
| Curve | C |
| Voltage (V) | 240V |
| Earth Leakage Protection Class | Type A |
| Earth Leakage Sensitivity | 30mA |
| Residual Current | 30mA |
| Breaking Capacity | 6kA |
| Overcurrent trip characteristic | C Curve |
| Earth Fault Wave Form | Type A |
| IP Rating | IP20 ( IP40 Enclosed ) |
| Number of Poles | 1P+N |
