PSA LIF6800 | 240V Photoelectric Smoke Alarm with 9V DC Battery Backup

The PSA LIF6800 Smoke Alarm is designed with advanced photoelectric sensing technology, providing optimal performance and minimizing false alarms. This device has a 240V AC power supply and a 9V battery backup, ensuring continuous protection even during power outages. The LIF6800 is built to withstand Australia’s extreme environmental conditions, incorporating features like reduced insect mesh, moisture resistance, and an anti-static chamber to enhance its reliability further.

Tested and certified to Australian Standards, this smoke alarm has been rigorously trialed across multiple sites to guarantee dependable performance. With easy installation via the QUICK SLIDE base and the ability to interconnect up to 24 units, the LIF6800 offers both convenience and superior safety.

240V Photoelectric Smoke Alarm + Battery Backup Features:

Advanced Photoelectric Sensor: Reduces false alarms and enhances detection in high-humidity environments.

Reliable Power Supply: 240V AC with 9V battery backup for uninterrupted operation.

Durable Design: Includes reduced insect mesh, moisture resistance, and anti-static chamber for long-lasting reliability.

Interconnectivity: Capable of connecting up to 24 units for comprehensive coverage.

PSA LIF6800 FAQ:

Q: Can the LIF6800 be interconnected with other alarms?
A: Yes, it can be interconnected with up to 24 units, either hard-wired or using a wireless base.

Q: How does the alarm handle false triggers from insects or dust?
A: To minimise false alarms, the advanced sensor includes a reduced insect mesh and an anti-static chamber.

Q: What is the alarm volume?
A: The alarm emits a loud 85dBA sound at 3 meters, ensuring it is easily heard.

Q: Is the LIF6800 tested and certified?
A: Yes, it is ActivFire Certified and complies with Australian Standards AS3786:2014.

Q: Why does my PSA product have the old logo and a 5-Year Warranty on the box?
A: PSA is in the process of rebranding its logo and packaging. Some boxes may still have the previous logo and mention a 5-Year Warranty.

Q: Is my PSA product still covered under the new warranty?
A: Yes, we can assure you that your PSA product comes with a 10-year Warranty, regardless of what is printed on the packaging.

Specification

Details

Sensor Type

Photoelectric Advance Sensor

Supply Voltage

240V AC 50Hz

Power Consumption

10mA max per alarm, 4mA (standby)

Battery Back-up

9V battery (Duracell Alkaline supplied)

Interconnecting

Interconnectable up to 24 units

Alarm Volume

85dBA at 3 metres

Alarm Signal Pattern

ISO8201 (T3 - Repeat 3 long beeps)

Temperature Range

0˚C - 40˚C

Humidity Range

Up to 93% RH (non-condensing)

Hush Function

Silences alarm for 9 minutes
Red LED flashes every 10 seconds
Dense smoke will override hush function

Low Battery Hush

Silence low battery beeping for 8 hours

Alarm Duration

Alarm will sound for as long as smoke is detected, then unit will automatically reset when smoke clears.

Alarm Indication

Red LED flashes every second.
When interconnected, only the red LED of initiating unit will flash.

Alarm Memory

Red LED flashes 3 times every 40 seconds.
Pressing Test button will sound a short beeping sequence.

Chamber Monitoring

3 beeps every 40 seconds.
Indicates maintenance is required.

Indicator LEDs

Green LED - Power indicator
Red LED - Alarm status indicator, differentiated by frequency of flash.

Wiring Terminal

9V, Active, Switch, Neutral, Loop

Dimensions

130mm (diameter) x 45mm (depth)

Approvals

ActivFire, SAI Global, RCM, AS3786:2014

TYPE

VALUE

Type

Smoke Alarm

Brand

PSA

Colour

White

Brand	PSA Products
SKU	LIF6800
Barcode #	9318475002155
Package Weight	0.350kg
Package Width	0.140m
Package Height	0.055m
Package Length	0.140m
